QUINT-PS/ 1AC/24DC/ 5
11
Connection to various systems
TN-S
L
N
PE
TN-C
L
PEN
TT
L
PEN
iT
L1
L2(N)
L N PE
+ ?
L N PE
+ ?
L N PE
+ ?
L N PE
+ ?
L1
L2
L3
N
PE
L1
L2
L3
PEN
L1
L2
L3
N
L1
L2
L3
L N PE
+ ?
L N PE
+ ?
L N PE
+ ?
L N PE
+ ?
The connection for 100 V AC ... 240 V AC is established using the L, N, and P screw connections.
The device can be connected to 1-phase AC networks or to two of the phase conductors of three-phase systems (TN, TT or
IT systems in accordance with VDE 0100-300/IEC 60364-3) with nominal voltages of 100 V AC ... 240 V AC.
The device also continues to work on short-term input voltages > 300 V AC.
For operation on two of the phase conductors of a three-phase system, an isolating facility for all poles must
be provided.
12
Input
CAUTION
If an internal fuse is triggered, there is most
probably a malfunction in the device. In this
case, the device must be inspected in the
factory!
Protection of the primary side
tpu
13
C2
DC
Ι <
Ou
tD
14 4V
OK -
Ι N
-
+
5A
-
The device must be installed in acc. with the regulations as in
EN 60950. It must be possible to disconnect the device using
+
+
a suitable isolating facility outside the power supply.
The primary side line protection, for example, is suitable. For
o t
Bo
s
device protection, there is an internal fuse. Additional device
DC
OK
protection is not necessary.
2 ,5
18-
9
V
Recommended backup fuse for mains protection
AC
0-2
40
Inp
ut
L
10
N
V
PE
Power circuit-breaker 6 A, 10 A or 16 A, characteristic B (or
identical function). Connect a suitable fuse upstream for DC
applications!
103127_en_04
PHOENIX CONTACT
